Thermally Conductive Encapsulant TS8866
Thermally Conductive Encapculant TS8800
MOQ :0 piece
Lead Time :0 Days
Seller Support : Trade Authenticity Guaranteed & Accepting
Payment : L/C,T/T,Pay Pal,Other
Departure Port : Shenzhen
Product details
Supply Ability
- Supply Ability:0 piecesWarranty(Year):0 Year
Packaging & Delivery
- Length:0 cmWidth:0 cm
- Height:0 cm
- Packaging:0 piece
Product Specifications
- Brand name:China Tensan
Product Description
Features & Benefits of LED Light Potting TS8800
Two-component silicone potting, 1 to 1, curing at room temperature.
l REACH, ROHS, certified
l Good waterproof
l Good thermal conductivity
l Easy to mix and use
Potting Silicone Encapsulation
LED Light Potting TS8800
l Power moduls
l Adaptors
l Transformers
l Ballasts
l Sensors
l Electric control units product
Description of LED Light Potting TS8800
Tensan silicone 1 to 1 encapulants are supplied as two part liquid component kits.
After mixing, two parts silicone will be cured as a flexible elastomer, which is well used for the protection of electrical and PCB system assemble application.
The duration of application and the curing time at room temperature are independent of the number of materials.
Packing Information of LED Light Potting TS8800
20KG/25KG/BUCKET
24 BUCKET/PALLET
Storage and Validity of LED Light Potting TS8800
Stored in room temperature, and in a cool, ventilated, dry place.
Shelf life: 6 month
Typical Properties of LED Light Potting TS8800
Item | Index |
Color | Part A: gray Part B: White |
Viscosity mPa·s (25℃) | Part A: 4500 Part B: 3800 |
Specific Gravity ( Cured ) | 1.8 |
Mix Ratio | 1:1 |
Viscosity mPa·s (25℃) | 4500 |
Density g/cm3 (25℃) | 1.60±0.05 |
Working Time at 25℃ (minutes) | 30-60 |
Heat Cure Time Hr/℃ | 0.5/80 |
Hardness (Shore A) | 45 |
Thermal Conductivity (W/mK) | 0.6 |
Dielectric Constant (1MHz 25℃) | 2.5 |
Dielectric Strength kV/mm (25℃) | 18 |
Volume Resistivity (DC500V ) Ω· cm | 1.5×1015 |
UL 94 Flame Classification | 94 V-1 |
